▲ Support Intel Sandy Bridge/Ivy Bridge series processors, LGA1155 socket
▲ Support 1 SATA interface, 1 MSATA interface, 8 USB2.0
▲ Supports a single 204 Pin SO-DIMM to 16GB DDR3 1600MHz
▲ Support 1 front Audio, 1 back Audio, 1 Audio amplifier
▲ Support 1 COM, support RS232 mode
▲ Support 1 WIFI/4G module
▲ Support 1 RJ45 Gigabit LAN interface
▲ Support VGA/HDMI/LVDS display interface, and support synchronous dual-display
▲ Support Win7, Win10 32/64 bit, Linux operating system
▲ Support DC12V DC power input
| Product Profile | ||
Product Name | AIO HM65 All In One Computer Motherboard | |
| CPU | Intel 2nd/3rd Celeron、Pentium、I3、I5、I7 Series Processor | |
Chipset | HM65 | |
Internal Memory | Single Channel DDR3 1600MHz 1*204Pin DDR3 SO-DIMM 16GB | |
Storage Interface | Support MSATA Hard disk | |
Display Interface | 1*HDMI 1*VGA | |
Network | 1 Gigabit LAN, RTL8111F LAN Chip | |
SATA | 1*SATA，1*4Pin Power socket，Support SATA 2.0 | |
USB | 4*USB 2.0 | |
Audio | 1(Mic-in、Line-out) | |
Product Size | 170*170MM DC 12V Motherboard | |
Features：
1.Well-cooling system with Good thermal material aluminum base for motherboard
2.All-solid electric capacitor for motherboard
3.PCB Copper plating technology for Motherboard
4.Independent power supply designed for Motherboard CPU
5.Zero burning protection circuit for Motherboard
6.Dual safety device stabilize voltage and current for load data uniformly
