▲Support for the Intel Xeon LGA1366 / Core i7-9xx processor
▲Supports 4 SATA interfaces and 12 USB2.0
▲High speed DDR 3 dual channel memory slot: support 1066 / 1333 / 1600 MHz maximum capacity 16G memory
▲Support for the PCIE expansion slot * 2
▲Support for RJ 45 Gigabit network card interface
▲4-layer PCB bottom plate, 4 + 1 phase power supply
▲Support for 5.1 sound channel ALC662 chip
| Product Profile | ||
Product Name | X58 V1608 Computer Motherboard | |
| CPU | Support Intel LGA1366 series processors | |
Chipset | AF82801JIB/JIR/IO/IR | |
Internal Memory | 2*DDR3 DIMM 1066/1333/1600MHz 16GB | |
Storage Interface | 4*SATA2.0 | |
Display Interface | / | |
Network | 1 Realtek Gigabit network card | |
PCIE Solt | 1 *PCIE X16 slot; 1 *PCIE X1 slot | |
USB | 8*USB2.0 | |
Audio | 1*Line out；1*Mic In；1*Line In；1*F_Audio Built-in | |
Product Size | 187*224mm*4L ATX motherboard | |
Features：
1.Well-cooling system with Good thermal material aluminum base for motherboard
2.All-solid electric capacitor for motherboard
3.PCB Copper plating technology for Motherboard
4.Independent power supply designed for Motherboard CPU
5.Zero burning protection circuit for Motherboard
6.Dual safety device stabilize voltage and current for load data uniformly
