-Support Intel Xeon E5 LGA2011-V3 pin processors
-Supports 4-channel DDR3*4 memory
-2 M.2 (NVMe protocol)
-Supports 6* SATA ports
-The rear IO provides 2 USB3.0 and 6 USB2.0 ports
-Built-in plug-in can expand 2 USB3.0, 2 USB2.0 ports
-1 x Gigabit network card, support PXE and network wake up function
-6 layer PCB base plate, 8 phase power supply
-2 * PCIE X16 slots, 2 * PCIE X1 slots
-1*CFAN+3*SFAN, 1* digital display DEBUG
-Support Windows7 Windows10 Windows11
| Product Profile | ||
Product Name | X99 DS3 Computer Motherboard | |
| CPU | Intel Xeon E5 LGA2011-V3 pin CPU | |
Chipset | B85 | |
Internal Memory | 4*DDR3 DIMM four channels, 1066/1333/1600/1866MHz (MAX) Maximum support 128G (32G*4) | |
Storage Interface | 2*M.2 slots (NVME protocol: PCIE 3.0 X4) 6*SATA ports (SATA3.0*4 + SATA2.0*2) | |
Display Interface | / | |
Network | 1RJ45 interface | |
PCIE Solt | PCIE1/3: PCIE X16 3.0 slots (from CPU) PCIE2/4: PCIE X1 2.0 slots (from PCH) | |
USB | 2*USB3.0 6*USB2.0 | |
Audio | Realtek HD audio chip | |
Product Size | 216*283mm*6L ATX motherboard | |
Features：
1.Well-cooling system with Good thermal material aluminum base for motherboard
2.All-solid electric capacitor for motherboard
3.PCB Copper plating technology for Motherboard
4.Independent power supply designed for Motherboard CPU
5.Zero burning protection circuit for Motherboard
6.Dual safety device stabilize voltage and current for load data uniformly
